YA-PS01 Hospital Transport Stretcher


Model: YA-PS01

Overall SizeL 2100*W 760*H 560~890 mm

Loading capacityDynamic load 318kg

Functions: Backrest, Footrest, High-low, Trendelenburg,Reverse-trend

Certificate: CE / ISO

After-sale Service: Online technical support

Warranty:  3-Year on Frame and Welds, and 1-Year on Parts

  • Product Details
  • Downloads

The ergonomic pushing handle, easy access brake pedal, and excellent steering functions are all features that contribute YA-PS01 to being a very nice option for patient transfer. Not only patient transfer, with safety protection and functionality of various patient positions, the YA-PS01 stretcher is also being used for the platform in the ER area.

Main features

- Two-column structure, accessible for C-arm

- The ergonomic push handle can be quickly raised with one click and can be hidden under the head of the bed when not in use.

- Robust collapsible railing, easy to lock up

- The bed surface is made of non-metallic X-ray transparent material, which is formed in one piece without splicing to ensure safety.

- With fifth-wheel steering function

- The central brake has 3 levels that can be adjusted

- Moulded base chassis with reservation for oxygen cylinder

- The foot operation pedal on available on both sides

- Bumper caster located on the four corners

- X-ray translucent platform (optional)

- Monitor shelf (optional)

Technical parameter

Overall size(L*W*H)2100*760*560mm (82.5″ x 30″ x 22″)
Height adjustment560-890mm (22″ – 35″ )
Back section adjustment0-90°
Knee section adjustment0-35°
Reverse trendelenburg0-18°
CastorDia 200mm ( 8″ )
Loading capacityDynamic load 318kg (700 Ibs)
