The YA-DH5-2 is an economical electric profiling care bed with functions that can be adjusted to meet the different needs of people. The full-length side rail can prevent people from falling risk. This bed significantly reduces costs and meets the low-budget needs of home care and nursing care centers.
Main features
- Electrically operated profiling bed for community and nursing home use
- Safe work load (SWL) 180Kg
- Variable height (345mm -745mm)
- Adjustable self-locking side rails providing additional safety which can be released at both head and foot ends
- Remote handset control
- High-quality castors (castor diameter: 100mm)
- Quick and easy assembly in limited space
Options
- Lifting pole with triangle
- Urine bag stand
- Battery backup
Technical parameter
| Model | YA-DH5-2 |
| Overall size | 2140*1010 *345mm (84″ x 40″ x 14″) |
| Lying size | 1900*900 mm (75″ x 35.5″ ) |
| Height adjustable | 345-745mm (14″ – 29.5″ ) |
| Backrest adjustable | 0-75° |
| Footrest adjustable | 0-40° |
| Trendelenburg | 0-12° |
| Reverse-Trendelenburg | 0-12° |
| Loading capacity | 180kg (395 Ibs） |
| Caster | Dia 100mm ( 4″ ) |
