The YA-PD5-2 Pediatric Bed is a state-of-the-art children's bed. Warm and inviting, this bed helps to bring an element of home into the clinical environment. It provides excellent access for nursing staff with electric positioning, telescopic side rails, and column construction mechanism. The YA-PD5-2 has very high safety parameters and looks great with a child-friendly design.
Main features
- Remote control and nurse control
- Electronic adjustment of backrest, legrest, and height positions
- Manual CPR (for backrest), electronic CPR
- One button chair position
- Auto-regress to remove the pressure of the abdomen when adjusting the backrest
- Auto-counter to provide the patient from sliding onto foot end
- Foldable side rails and removable head/foot boards made of ABS
- 4 sections lying surface made of HDPE
- 360° turning castors (125 mm), 2 of them with brakes.
- Bumpers on 4 corners
- Urine bag holder
- Holes for IV pole and lifting pole on 4 corners
- Electrostatic epoxy polyester powder metal parts
- Angle indicators on side rails
Main Benefits of YA-PD5-2 Pediatric Bed
1. Double-Column Lifting Structure
The YA-PD5-2 features a double-column lifting structure for electric height adjustment. The bed height can be adjusted from 600 to 1000 mm, allowing caregivers to adapt the bed position to different nursing and care tasks.
2. Adjustable Side Rails for Pediatric Care
The telescopic side rails can be adjusted to support different care situations. Their design allows caregivers to access the child when needed while maintaining the bed's side protection features.
3. Electric Positioning for Flexible Care
The electric positioning system supports backrest and legrest adjustment, bed-height adjustment, Trendelenburg and reverse Trendelenburg positioning, and a one-button chair position. These functions allow the bed to be configured for different patient positioning and nursing requirements.
4. Designed Around Practical Care Details
Additional features include nurse and remote controls, manual and electric CPR functions, side-rail angle indicators, corner bumpers and holders for an IV pole and lifting pole. These details support daily operation and nursing workflows in pediatric care environments.
Optional configuration
- Translucent platform for x-ray
- HPL platform
- Bed frame extension
- Weighing scale
- Night light under the bed
- Brake warning system
- 5th direction castor
- Battery backup
Technical parameter
| Model | YA-PD5-2 |
| Overall Size | 1840*970*600mm |
| Mattress size | 1600*750*100mm |
| Height adjustment | 600~1000mm |
| Back-rest adjustment | 0-70° |
| Knee-rest adjustment | 0-30° |
| Reverse Trendelenburg /Trendelenburg | 0-12° |
| Loading capacity | 240 kg (530 Ibs) |
| Castor | Dia 150mm (6 inches) |
