YA-04M Hydraulic Operation Table X-ray Function


Model: YA-04M

Overall Size: 2100*500*750-950mm

Maximum Safe Load :230kg

Certificate: ISO/CE

  • Product Details

 Watch Vedio

Main features

- The YA-04M is designed for procedures in the range of general surgery, vascular surgery, cardiosurgery, neurosurgery,urology, proctology, gynaecology and others.
- Four (Five) section table top with five (six) segments

- Operating table surfaces are easy to clean and resistant to disinfecting agents

- Table top height adjustment with use of hydraulic foot pump

- Table top longitudinal shift is manually executed for C-arm, besides, the table top is X-ray translucent, which enables taking X-ray pictures and monitoring the patient with a C-arm

- Back rest segment angle inclination, leg rest segment (regarding five and six segments table top), head rest segment functions are supported by gas springs

- Kidney elevator (in case of five and six segment table top adjusted manually with use of crank placed at patient’s head side)

- Lateral tilts, Trendelenburg and Reverse Trendelenburg, Longitudinal shift functions are executed by the gear system

- Divided, two parts leg rest segments are adjusted by means of gear transmission

Technical parameter

Table Length84" (2100 mm)
Table Width20" (500 mm) (22.5" with extenders)
Table Height Range30" to 38" (750 to 950 mm)
Table Slide Range8" (200 mm) to head, 8" (200 mm) to foot (16" total)
Table Shipping Weight616 lbs. (280 kg)
Trendelenburg / Reverse20°/ 15°
Lateral Tilt (left/right)15° / 15°
Head Section+45° to -90°
Back Section+45°
Leg Section0 to -90°
Spread Angle of leg plates90°
Kidney Elevator height adjustment4” (100mm)

Standard accessory

Head Rest 1

Body Support, Large 2

Body Support, Small 1

Shoulder Rest 2

Kidney Bridge 1

Anaesthetic Screen 1

Knee Crutch 2

Arm support 2

Cushion 1

Body Restraint Strap 1 Optional Components
