| Technical parameters |
| Model | YA-DM3PCM |
| Size | 2230*1100*520-770mm |
| Lying surface | 2045*900mm |
| Overall Height | 520-770mm |
| Back secticn adjustable | 0° to 75° |
| Knee secticn adjustable | 0° to 40° |
| Safe working load | 205kg |
| Specification |
| Bed Frame | Electrophoresis and powder coating |
| Bed platform | MS perforated platform with ventilation hole, molded |
| Motor | Quiet and robust electric actuators provide reliable operation |
| Hand remote controller of all electrically operated functions and movements |
| Handrails | Four split side rail,drop down under the bed platform |
| Head and Foot board | Detachable head/foot board with easy lock |
| Castors | Central brake system with wheel diameter of 125mm |
| Bumper castors | Bumper castors on 4 corners of bed |
| Angle indicator | With angle indicator embeded in the railing for back |
| Special Features |
| Auto-counter function | Auto-counter to provide the patient from sliding onto foot end |
| Manual backup | Manual backup for emergency situation |
| Standard Accessories |
| Head/Foot Board | 2 pieces |
| Side Rails | 4 pieces |
| Bed Frame | 1 set |
| Bed Boards | 4 pieces |
| Casters | 4 pieces |
| IV Pole Holder | 4 pieces |
| IV Pole | 1 piece |
| Drainage Bag Holders | 2 pieces |
