| Technical parameters |
| Model | YA-DH3ACM |
| Size | 2140*980*500-800mm |
| Lying surface: | 1900*840mm |
| Overall Height: | 500-800mm |
| Height from platform to railing top | 430mm |
| Back secticn adjustable | 0° to 75° |
| Knee secticn adjustable | 0° to 40° |
| Safe working load | 175kg |
| Specification |
| Bed Frame | Electrophoresis and powder coating |
| Bed platform | MS perforated platform with ventilation hole, molded |
| Motor | Quiet and robust electric actuators provide reliable operation |
| Hand remote controller of all electrically operated functions and movements |
| Handrails | Collapsible aluninum railing extra height |
| Head and Foot board | Detachable wooden head/foot board with easy lock |
| Castors: | Central brake system with wheel diameter of 125mm |
| Bumper castors | Bumper caster on four corners |
| Special Features |
| Auto-counter function | Auto-counter to provide the patient from sliding onto foot end |
| Standard Accessories |
| Head/Foot Board | 2 pieces |
| Side Rails | 2 pieces |
| Bed Frame | 1 set |
| Bed Boards | 4 pieces |
| Casters | 4 pieces |
| IV Pole Holder | 4 pieces |
| IV Pole | 1 piece |
| Drainage Bag Holders | 2 pieces |
