Model: YA-M5PCM01
Overall Size: 2490*1100*520-770mm
Safe Working Load: 195kg
Functions: Back section adjustable, Knee section adjustable,High-Low,Trendelenburg,Reverse trendelenburg
Features:
1. Four split side rail,drop down under the bed platform
2. Foldable hand crank
3. Detachable head/foot board with easy lock
4. Central brake system with wheel diameter of 125mm
5. With articulated ABS soft joint between different platform sections
6. With angle indicator embeded in the railing for back and trendenleburg adjustment(optional)
7. Retractable 5th wheel for direction(optional)
Technical features:
| Technical parameters | |
| Model | YA-M5PCM01 |
| Overall Size | 2490*1100*520-770mm |
| Lying surface | 2300*900mm |
| High-Low | 520-770mm |
| Back section adjustable | 0° to 75° |
| Knee section adjustable | 0° to 40° |
| Trendelenburg | 0° to 12° |
| Reverse trendelenburg | 0° to 12° |
| Safe working load | 195kg |
| Specification | |
| Bed Frame | Electrophoresis and powder coating |
| Bed platform | With articulated ABS soft joint between different platform sections |
| Handrails | Four split side rail,drop down under the bed platform |
| Head and Foot board | Detachable head/foot board with easy lock |
| Cranks | 4 peaces foldable hand cranks |
| Castors | Central brake system with wheel diameter of 125mm |
| Bumper castors | Bumper castors on 4 corners of bed |
| Angle indicator | With angle indicator embeded in the railing for back |
| Standard Accessories | |
| Head/Foot Board | 2 pieces |
| Side Rails | 4 pieces |
| Bed Frame | 1 set |
| Bed Boards | 4 pieces |
| Casters | 4 pieces |
| IV Pole Holder | 4 pieces |
| IV Pole | 1 piece |
| Drainage Bag Holders | 2 pieces |
